Cold Shrink tube for antenna to 1/2’’ cable
Cold shrink termination kits is a fast and easy way to weatherproof a connection. Simply position the pre- expanded tubing over the connection that you are protecting and pull the rip cord. The tubing compresses to form a weatherproof seal.
All without heat, special tools or a time-consuming installation procedure. And it's easily removed when system maintenance is required.
Cold shrink termination kits is designed to seal the connection between the base station antenna and the 1/2" flex & super flex coaxial cable. It is widely used in the wireless cell sites.
Feature:
1. Simple installation, requires only workman's hands.
2. No tool or heat required.
3. Seals tight, retains its resiliency and pressure even after years of aging and exposure.
4. Resists moisture.
5. Wide range, size accommodation.
6. Resists acids and alkalies.
7. Resists ozone and ultraviolet light.
8. Resists fluid splashes.
9. Resists fire - will not support flame.
Technical Spec:
| Item No. | TEL-A12-S |
| Application. | Cold Shrink termination kits |
| Size. | Antenna to 1/2" |
| Material. | Liquid Silicone Rubber Cold Shrink termination |
| Include. | One Liquid Silicone rubber tube |
| Color | Black Cold Shrink termination kits |
|
Product |
Tube Inner Diameter (mm) |
Cable range(mm) |
|
Silicone Cold Shrink Tube |
φ15 |
φ4-11 |
|
φ20 |
φ5-16 |
|
|
φ25 |
φ6-21 |
|
|
φ28 |
φ6-24 |
|
|
φ30 |
φ7-26 |
|
|
φ32 |
φ8-28 |
|
|
φ35 |
φ8-31 |
|
|
φ40 |
φ10-36 |
|
|
φ45 |
φ11-41 |
|
|
φ52 |
φ11.5-46 |
|
|
φ56 |
φ12.5-50 |
|
| Remarks: |
|
|
| Tube diameter and tube length can be customized according to customer's requirements. | ||
