TEL-NMC.LMR400-RFC
| Electrical | |
| Characteristics Impedance | 50 Ohm |
| Frequency Range | DC-11GHz |
| VSWR | ≤1.15(3.0G) |
| Dielectric Withstanding Voltage | ≥2500V RMS,50Hz,at sea level |
| Dielectric Resistance | ≥5000MΩ |
| Contact Resistance | Center Contact ≤1.0mΩ
Outer Contact ≤0.4mΩ |
| Material and Plating | ||
| Material | Plating | |
| Body | Brass | Ni |
| Insulator | PTFFE | / |
| Center conductor | Brass | Au |
| Environmental | |
| Temperature range | -40~+85℃ |
